A Merit Series Power Conditioner is the perfect low-cost AC power solution for any rack mount system. Install an M-8x2 in to the top slot of your rack and the eight switched outlets in the rear panel will power up and protect all your equipment up to a 15-amp load. The M-8x2 is designed for applications where lights are not required.
M-8x2 Specifications:
- Maximum Output Current: 15 amps
- Line Cord: 6 ft. captive 14 AWG with 3-conductor plug
- Operating Voltage: 120VAC 60Hz
- Spike Protection Mode: Line to neutral
- Energy Dissipation: 170 joules
- Peak Impulse Current: 12000 amps
- Maximum Continuous Operating Voltage: 130 VAC RMS
- Let Through Voltage (@ 125 amps 8/20uS waveform) 400 volts
- Noise Attenuation: Transverse mode: Greater than 23dB 200Khz to 10 Mhz
- Dimensions: 1.75 H x 19 W x 3.75 D
- Weight: 4.9 lbs.
- Safety Agency Listing: cTUVus
- Warranty: Merit Series units are protected by a limited three year warranty covering defects in materials and workmanship.
Main Features
- 8 rear panel outlets and 1 front panel outlet.
- AC noise filtering to reduce radio frequency and electromagnetic interference (RFI/EMI).
- Spike; surge protection ensures equipment stays safe and your power stays clean.
General Information
Name: Panamax M-8X2 Merit Series M-8x2 Power Conditioner
Category: Panamax, Batteries & Power Supplies, Power Conditioners
UPC Code: 654061028307
Country of Origin: China. Country of origin is subject to change.
