Pass ; Seymour CS20AC1-GRY Heavy Duty Grade 3-Way Toggle Switch; 1-Pole, 120/277 Volt AC, 20 Amp, Gray

The Pass & Seymour 1-Pole Toggle Switch in gray color is designed for durability and reliable performance. Featuring a positive break cam mechanism, it minimizes arcing and ensures long-lasting operation. This switch offers three-way operation for controlling multiple locations, and its heavy-duty toggle bumpers provide continuous, quiet operation. The oversized silver alloy contacts ensure high performance, while the switch accommodates 10 - 14 AWG copper or copper-clad wires for optimal conductivity. Its sturdy thermoplastic polycarbonate actuator resists chipping and cracking, even under high mechanical stress. This commercial specification-grade switch includes a side-wiring connection for easy installation. Measuring 1.320 inches x 1.073 inches x 3.281 inches, it is rated for 120/277 VAC and 20 Amps. The switch features a rugged glass-reinforced nylon back, a locking support for face and back body separation, and a corrosion-resistant one-piece steel strap with an integral ground. It also includes a tri-drive terminal and screws for precise mounting and is UL listed/CSA certified for safety and quality.

Product Specification :

• Positive break cam mechanism for minimized arcing and durability
• Three-way operation for multiple controlling options
• Voltage rating of 120/277 VAC and current rating of 20 Amps
• Accommodates 10 - 14 AWG copper/copper-clad wires for high conductivity
• UL listed and CSA certified, featuring corrosion-resistant steel strap and tri-drive terminal for precise mounting
