A proven, highly reliable solution, the VISTA-128BPT light commercial alarm panel supports burglary applications and a vast number of hardwire, V-Plex® and wireless options and features that maximize installation flexibility and simplify end-user operation. It is compatible with a wide range of AlarmNet® communications products for alarm reporting, uploading /downloading and remote services.
Maximum zone capacity -128
Maximum standard hardwire zones - 9
Maximum wireless expansion zones 127
Supports 119 additional V-Plex expansion zones
Accommodates 150 user codes with 7 authority levels
Accommodates 32 Keypad macro commands per system
Keeps log of up to 512 events
Provides the ability to control 8 separate partitions independently
Programmable to meet SIA false alarm prevention specifications (part number V128BPTSIA)
Main Features
- Provides nine style-B hardwired zones
- Supports up to 119 additional zones using a built-in polling (V-Plex, multiplex) loop interface
- Supports up to 127Wireless zones using up to two 5800 seriesWireless receivers (fewer if using hardwire and/or polling loop zones)
- Provides one power-limited bell circuit delivering 1.7Amp (max) at 12VDC
- Provides the ability to control eight separate partitions independently, each functioning as if it had its own separate control
- Accommodates 150 user codes with seven authority levels
- Accommodates 32 keypad macro commands per system
- Keeps a log of up to 512 events
- Supports up to 16 compatible two-wire smoke detectors on zone 1
- Zone 7 may be used for keyswitch arming/ disarming
General Information
Name: Honeywell Home V128BPTSIA VISTA SIA Approved Enhanced Commercial Burglary Alarm Control Panel, UL Listed
Category: Honeywell Home, Intrusion, Smart Home, Intrusion, Alarm Control Panels & Keypads, Wireless Intrusion, Smart Hubs & Keypads, Control Panels
UPC Code: 619172084307
Country of Origin: Mexico. Country of origin is subject to change.
